Auto-Dimension MEP
The app helps insert and merge dimensions automatically to pipe/duct/cable trays/conduits in your project
Description
Auto-Dimension MEP is a powerful Autodesk® Revit® add-in designed to streamline the process of adding dimensions and tags to your MEP elements. Whether working with pipes, ducts, cable trays, or conduits, this tool automates dimensioning, saving you valuable time.
The app automatically retrieves pipe diameters and lengths directly from your project, allowing for quick and precise dimension insertion for selected pipes. It also simplifies adding dimensions between connectors, making it an essential tool for accurate and efficient MEP modeling.
It supports adding dimensions to 3D views and, when adding tags, it locks the current view and creates a new one for precise tagging, ensuring your original view remains intact. Auto-Dimension MEP is the ultimate tool for efficient and accurate MEP modeling.
For MEP Fabrication, the app exclusively supports the “Add dimension between connectors” feature, making it an essential tool for efficient and precise MEP modeling.
